Special Motion Commands
4.6 Settable path reference (SPATH, UPATH)
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
259
Program code
N10 G1 X0 A0 F1000 SPATH
N20 POLY PO[X]=(10,10) A10
or:
Program code
N10 G1 X0 F1000 UPATH
N20 POLY PO[X]=(10,10) A10
In block
N20, path S of the FGROUP axes is dependent on the square of curve parameter U.
Therefore, different positions are obtained for the synchronous axis A along path X,
according to whether SPATH or UPATH is active.
Further information
During polynomial interpolation - and therefore this always involves polynomial interpolation
in a strict sense (POLY), all spline interpolation types (ASPLINE, BSPLINE, CSPLINE) and
linear interpolation with compressor function (COMPON, COMPCURV) - the positions of all
path axes i are specified by the polynomial pi(U). Curve parameter U moves from 0 to 1
within an NC block, therefore it is standardized.
The axes to which the programmed path feed is to relate can be selected from the path axes
by means of language command FGROUP. However, during polynomial interpolation, an
interpolation with constant velocity on path S of these axes usually means a non constant
change of curve parameter U.
Control behavior for reset and machine/option data
The G code, defined by MD20150 $MC_GCODE_RESET_VALUES[44] (45th G code group)
is effective after a reset. In order to maintain compatibility with existing installations, SPATH
is set as default value.
The initial state for the type of smoothing is defined with
MD20150 $MC_GCODE_RESET_VALUES[9] (10th G code group).
The axis-specific machine data MD33100 $MA_COMPRESS_POS_TOL[<n>] has an
extended significance: It contains the tolerances for the compressor function and for
smoothing with G642.
