Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
590 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Execute the "Continuous modal write of online tool offset" function
Parameter:
Number of the polynomial function
Type: INT
Range of values: 1 to 3
<function>:
Note:
Must match the setting for
FCTDEF.
Main run variable for which a function value is to
be calculated using the polynomial function
defined with
FCTDEF.
<reference value>:
Type: VAR REAL
Number of the wear parameter (length 1, 2 or 3)
in which the offset value is to be added.
<tool parameter:
Type: INT
Number of the channel in which the online tool
offset is to take effect.
Type: INT
<channel>:
Note:
A channel number only has to be specified if the
offset is not to take effect in the active channel.
Number of the spindle for which the online tool
offset is to take effect.
Type: INT
DO FTOC:
<spindle>:
Note:
A spindle number only has to be specified if the
offset is to be applied to a non-active grinding
wheel rather than the active tool which is
currently in use.
Note
FTOCON must be activated in the destination channel.
