Tables
16.1 Instructions
Job planning
710 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
<= Comparison operator, less than or equal
to
PGAsl
Arithmetic functions (Page 63)
= Assignment operator
PGAsl
Arithmetic functions (Page 63)
>= Comparison operator, greater than or
equal to
PGAsl
Arithmetic functions (Page 63)
/ Operator for division
PGAsl
Arithmetic functions (Page 63)
/0
…
…
/7
Block is skipped
(1st skip level)
Block is skipped
(8th skip level)
PGsl
A Axis name m/s
PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
A2 Tool orientation: RPY or Euler angle s
PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
A3 Tool orientation: Direction/surface
normal vector component
s
PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
A4 Tool orientation: Surface normal vector
for beginning of block
s
PGAsl
Face milling (3D-milling A4, B4, C4, A5, B5, C5)
(Page 330)
A5 Tool orientation: Surface normal vector
for end of block
s
PGAsl
Face milling (3D-milling A4, B4, C4, A5, B5, C5)
(Page 330)
ABS Absolute value (amount)
PGAsl
Arithmetic functions (Page 63)
AC Absolute dimensions of
coordinates/positions
s
PGsl
ACC Effect of current axial acceleration m
PGsl
ACCLIMA Effect of current maximum axial
acceleration
m
PGsl
ACN Absolute dimensions for rotary axes,
approach position in negative direction
s
PGsl
ACOS Arc cosine
(trigon. function)
PGAsl
Arithmetic functions (Page 63)
ACP Absolute dimensions for rotary axes,
approach position in positive direction
s
PGsl
ACTBLOCNO Output of current block number of an
alarm block, even if "current block
display suppressed" (DISPLOF) is
active.
PGAsl
Suppress current block display (DISPLOF, DISPLON,
ACTBLOCNO) (Page
168)
