Siemens SINUMERIK 828D Programming Manual

Tables
16.1 Instructions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
711
Operation Meaning W
1)
Description see
2)
ADDFRAME Inclusion and possible activation of a
measured frame
PGAsl, FB1(K2)
Frame calculation from three measuring points in
space (MEAFRAME) (Page 298)
ADIS Rounding clearance for path functions
G1, G2, G3, ...
m PGsl
ADISPOS Rounding clearance for rapid traverse
G0
m PGsl
ADISPOSA Size of the tolerance window for
IPOBRKA
m PGAsl
Programmed end-of-motion criterion (FINEA,
COARSEA, IPOENDA, IPOBRKA, ADISPOSA)
(Page
274)
ALF LIFTFAST angle m PGAsl
Fast retraction from the contour (SETINT LIFTFAST,
ALF) (Page
118)
AMIRROR Programmable mirroring s PGsl
AND Logical AND PGAsl
Comparison and logic operations (Page 66)
ANG Contour angle s PGsl
AP Polar angle m/s PGsl
APR Read/show access protection PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page 40)
APRB Read access right, OPI PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page
40)
APRP Read access right, part program PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page
40)
APW Write access protection PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page 40)
APWB Write access right, OPI PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page 40)
APWP Write access right, part program PGAsl
Attribute: Access rights (APR, APW, APRP, APWP,
APRB, APWB) (Page 40)
APX Definition of the access right for
executing the specified language
element
PGAsl
Redefinition of system variables, user variables, and
NC language commands (REDEF) (Page
30)
AR Opening angle m/s PGsl
