Tables
16.1 Instructions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
715
Operation Meaning W
1)
Description see
2)
CASE Conditional program branch
PGAsl
Program branch (CASE ... OF ... DEFAULT ...)
(Page 89)
CDC Direct approach of a position
PGAsl
Approaching coded positions (CAC, CIC, CDC, CACP,
CACN) (Page 233)
CDOF
3)
Collision detection OFF m
PGsl
CDOF2 Collision detection OFF, for 3D
circumferential milling
m
PGsl
CDON Collision detection ON m
PGsl
CFC
3)
Constant feedrate on contour m
PGsl
CFIN Constant feedrate for internal radius
only, not for external radius
m
PGsl
CFINE Assignment of fine offset to a FRAME
variable
PGAsl
Coarse and fine offsets (CFINE, CTRANS)
(Page 293)
CFTCP Constant feedrate in tool center point
(center point path)
m
PGsl
CHAN Specify validity range for data
PGAsl
Definition of user variables (DEF) (Page 23)
CHANDATA Set channel number for channel data
access
PGAsl
Working memory (CHANDATA, COMPLETE, INITIAL)
(Page 212)
CHAR Data type: ASCII character
PGAsl
Definition of user variables (DEF) (Page 23)
CHECKSUM Forms the checksum over an array as a
fixed-length STRING
PGAsl
Checksum calculation using an array (CHECKSUM)
(Page 146)
CHF Chamfer;
value = length of chamfer
s
PGsl
CHKDM Uniqueness check within a magazine
FBW
CHKDNO Check for unique D numbers
PGAsl
Free assignment of D numbers: Checking D numbers
(CHKDNO) (Page 431)
CHR Chamfer;
value = length of chamfer in direction of
movement
PGsl
CIC Approach position by increments
PGAsl
Approaching coded positions (CAC, CIC, CDC, CACP,
CACN) (Page
233)
CIP Circular interpolation through
intermediate point
m
PGsl
