Tables
16.1 Instructions
Job planning
714 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
BSPLINE B-spline m PGAsl
Spline interpolation (ASPLINE, BSPLINE, CSPLINE,
BAUTO, BNAT, BTAN, EAUTO, ENAT, ETAN, PW,
SD, PL) (Page 234)
BTAN Tangential transition to first spline block m PGAsl
Spline interpolation (ASPLINE, BSPLINE, CSPLINE,
BAUTO, BNAT, BTAN, EAUTO, ENAT, ETAN, PW,
SD, PL) (Page 234)
C Axis name m/s PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
C2 Tool orientation: RPY or Euler angle s PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
C3 Tool orientation: Direction/surface
normal vector component
s PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page
323)
C4 Tool orientation: Surface normal vector
for beginning of block
s PGAsl
Face milling (3D-milling A4, B4, C4, A5, B5, C5)
(Page 330)
C5 Tool orientation: Surface normal vector
for end of block
s PGAsl
Face milling (3D-milling A4, B4, C4, A5, B5, C5)
(Page
330)
CAC Absolute position approach PGAsl
Approaching coded positions (CAC, CIC, CDC, CACP,
CACN) (Page 233)
CACN Absolute approach of the value listed in
the table in negative direction
PGAsl
Approaching coded positions (CAC, CIC, CDC, CACP,
CACN) (Page
233)
CACP Absolute approach of the value listed in
the table in positive direction
PGAsl
Approaching coded positions (CAC, CIC, CDC, CACP,
CACN) (Page
233)
CALCDAT Calculates radius and center point of
circle from 3 or 4 points
PGAsl
Calculate circle data (CALCDAT) (Page 705)
CALCPOSI Checking for protection zone violation,
working area limitation and software
limits
PGAsl
Checking for protection zone violation, working area
limitation and software limits (CALCPOSI) (Page
225)
CALL Indirect subroutine call PGAsl
Indirect subprogram call (CALL) (Page 190)
CALLPATH Programmable search path for
subroutine calls
PGAsl
Extend search path for subprogram calls (CALLPATH)
(Page
194)
CANCEL Cancel modal synchronized action PGAsl
Delete synchronized action (CANCEL) (Page 629)
