16.1 Instructions
Job planning
718 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
CT Circle with tangential transition m PGsl
CTAB Define following axis position according
to leading axis position from curve table
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABDEF Table definition ON PGAsl
Define curve tables (CTABDEF, CATBEND)
(Page 502)
CTABDEL Clear curve table PGAsl
Delete curve tables (CTABDEL) (Page 508)
CTABEND Table definition OFF PGAsl
Define curve tables (CTABDEF, CATBEND)
(Page
502)
CTABEXISTS Checks the curve table with number n PGAsl
Check for presence of curve table (CTABEXISTS)
(Page 508)
CTABFNO Number of curve tables still possible in
the memory
PGAsl
Curve tables: Check use of resources (CTABNO,
CTABNOMEM, CTABFNO, CTABSEGID, CTABSEG,
CTABFSEG, CTABMSEG, CTABPOLID, CTABPOL,
CTABFPOL, CTABMPOL) (Page 518)
CTABFPOL Number of polynomials still possible in
the memory
PGAsl
Curve tables: Check use of resources (CTABNO,
CTABNOMEM, CTABFNO, CTABSEGID, CTABSEG,
CTABFSEG, CTABMSEG, CTABPOLID, CTABPOL,
CTABFPOL, CTABMPOL) (Page 518)
CTABFSEG Number of curve segments still possible
in the memory
PGAsl
Curve tables: Check use of resources (CTABNO,
CTABNOMEM, CTABFNO, CTABSEGID, CTABSEG,
CTABFSEG, CTABMSEG, CTABPOLID, CTABPOL,
CTABFPOL, CTABMPOL) (Page 518)
CTABID Returns table number of the nth curve
table
PGAsl
Curve tables: Determine table properties (CTABID,
CTABISLOCK, CTABMEMTYP, CTABPERIOD)
(Page 511)
CTABINV Define leading axis position according to
following axis position from curve table
PGAsl
Read curve table values (CTABTSV, CTABTEV,
CTABTSP, CTABTEP, CTABSSV, CTABSEV, CTAB,
CTABINV, CTABTMIN, CTABTMAX) (Page 513)
CTABISLOCK Returns the lock state of the curve table
with number n
PGAsl
Curve tables: Determine table properties (CTABID,
CTABISLOCK, CTABMEMTYP, CTABPERIOD)
(Page 511)
CTABLOCK Delete and overwrite, lock PGAsl
Locking curve tables to prevent deletion and
overwriting (CTABLOCK, CTABUNLOCK)
(Page 510)
