Tables
16.1 Instructions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
725
Operation Meaning W
1)
Description see
2)
ENDWHILE End line of WHILE loop
PGAsl
Program loop with condition at start of loop (WHILE,
ENDWHILE) (Page 103)
ETAN Tangential transition to next traversing
block at spline begin
m
PGAsl
Spline interpolation (ASPLINE, BSPLINE, CSPLINE,
BAUTO, BNAT, BTAN, EAUTO, ENAT, ETAN, PW,
SD, PL) (Page 234)
EVERY Execute synchronized action on
transition of condition from FALSE to
TRUE
PGAsl
Cyclically checking the condition (WHEN,
WHENEVER, FROM, EVERY) (Page 553)
EX Keyword for value assignment in
exponential notation
PGAsl
Predefined user variables: Arithmetic parameters (R)
(Page 19)
EXECSTRING Transfer of a string variable with the
executing part program line
PGAsl
Indirectly programming part program lines
(EXECSTRING) (Page
62)
EXECTAB Execute an element from a motion table
PGAsl
Indirectly programming part program lines
(EXECSTRING) (Page 62)
EXECUTE Program execution ON
PGAsl
Deactivate contour preparation (EXECUTE)
(Page 707)
EXP Exponential function ex
PGAsl
Arithmetic functions (Page 63)
EXTCALL Execute external subprogram
PGAsl
Execute external subroutine (EXTCALL) (Page 195)
EXTERN Declaration of a subprogram with
parameter transfer
PGAsl
Subprogram call without parameter transfer
(Page
181)
F Feedrate value
(in conjunction with G4 the dwell time is
also programmed with F)
PGsl
FA Axial feedrate m
PGsl
FAD Infeed rate for soft approach and
retraction
PGsl
FALSE Logical constant: Incorrect
PGAsl
Definition of user variables (DEF) (Page 23)
FB Non-modal feedrate
PGsl
FCTDEF Define polynomial function
PGAsl
Online tool offset (PUTFTOCF, FCTDEF, PUTFTOC,
FTOCON, FTOCOF) (Page
404)
FCUB Feedrate variable according to cubic
spline
m
PGAsl
Feedrate response (FNORM, FLIN, FCUB, FPO)
(Page 458)
