Siemens SINUMERIK 828D Programming Manual

Tables
16.1 Instructions
Job planning
752 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
T Call tool
(only change if specified in machine
data; otherwise M6 command
necessary)
PGsl
TAN Tangent (trigon. function) PGAsl
Arithmetic functions (Page 63)
TANG Definition of axis grouping tangential
correction
PGAsl
Tangential control (TANG, TANGON, TANGOF, TLIFT,
TANGDEL) (Page 451)
TANGDEL Deletion of definition of axis grouping
tangential correction
PGAsl
Tangential control (TANG, TANGON, TANGOF, TLIFT,
TANGDEL) (Page
451)
TANGOF Tangential correction OFF PGAsl
Tangential control (TANG, TANGON, TANGOF, TLIFT,
TANGDEL) (Page 451)
TANGON Tangential correction ON PGAsl
Tangential control (TANG, TANGON, TANGOF, TLIFT,
TANGDEL) (Page
451)
TCA Tool selection/tool change irrespective
of tool status
FBW
TCARR Request toolholder (number "m") PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page 439)
TCI Load tool from buffer into magazine FBW
TCOABS
3)
Determine tool length components from
the orientation of the current toolholder
m PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page 439)
TCOFR Determine tool length components from
the orientation of the active frame
m PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page
439)
TCOFRX Determine tool orientation of an active
frame on selection of tool, tool points in
X direction
m PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page 439)
TCOFRY Determine tool orientation of an active
frame on selection of tool, tool points in
Y direction
m PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page 439)
TCOFRZ Determine tool orientation of an active
frame on selection of tool, tool points in
Z direction
m PGAsl
Tool length compensation for orientable toolholders
(TCARR, TCOABS, TCOFR, TCOFRX, TCOFRY,
TCOFRZ) (Page 439)
THETA Angle of rotation s PGAsl
Rotations of the tool orientation (ORIROTA, ORIROTR,
ORIROTT, ORIROTC, THETA) (Page 344)

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
