16.1 Instructions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
753
Operation Meaning W
1)
Description see
2)
TILT Tilt angle m
PGAsl
Programming of the tool orientation (A..., B..., C...,
LEAD, TILT) (Page 323)
TLIFT In tangential control insert intermediate
block at contour corners
PGAsl
Tangential control (TANG, TANGON, TANGOF, TLIFT,
TANGDEL) (Page 451)
TMOF Deselect tool monitoring
PGAsl
Grinding-specific tool monitoring in the part program
(TMON, TMOF) (Page 659)
TMON Activate tool monitoring
PGAsl
Grinding-specific tool monitoring in the part program
(TMON, TMOF) (Page
659)
TO Designates the end value in a FOR
counter loop
PGAsl
Count loop (FOR ... TO ..., ENDFOR) (Page 102)
TOFF Tool length offset in the direction of the
tool length component that is effective
parallel to the geometry axis specified
in the index
m
PGsl
TOFFL Tool length offset in the direction of the
tool length component L1, L2 or L3
m
PGsl
TOFFOF Deactivate online tool offset
PGAsl
Online tool length compensation (TOFFON, TOFFOF)
(Page 442)
TOFFON Activate online tool length offset
PGAsl
Online tool length compensation (TOFFON, TOFFOF)
(Page 442)
TOFFR Tool radius offset m
PGsl
TOFRAME Align the Z axis of the workpiece
coordinate system parallel to the
workpiece orientation by rotating the
frame
m
PGsl
TOFRAMEX Align the X axis of the workpiece
coordinate system parallel to the
workpiece orientation by rotating the
frame
m
PGsl
TOFRAMEY Align the Y axis of the workpiece
coordinate system parallel to the
workpiece orientation by rotating the
frame
m
PGsl
TOFRAMEZ As TOFRAME m
PGsl
TOLOWER Convert the letters of a string into
lowercase
PGAsl
Conversion to lower/upper case letters (TOLOWER,
TOUPPER) (Page 79)
TOOLENV Save current states which are of
significance to the evaluation of the tool
data stored in the memory
FB1(W1)
