8 Maintenance
8.4 Spare parts list
Manual
SIPART DR21
C73000-B7476-C143-08
227
8.4 Spare parts list
Item Figure Description Comments Order number
1
1.1
1.2
1.3
1.4
(1) Figure 8-1
(2) Figure 8-1
(3) Figure 8-1
--
Front module
Front module complete
Shaft screw (M3)
Tag plate cover
10 Tag plate labels
C73451-A3004-B1 12
D7964-L9010-S3
C73451-A3001-C5
C73451-A3001-C16
2
2.1
2.2
2.3
2.4
(2) Figure 8-2
(4) Figure 8-2
--
--
Housing
Plastic housing
Dummy covers for unoccupied slots
Clamps
10 self--adhesive sealing rings
(Front frame/panel)
C73451-A3004-C3
C73451-A3000-C1 1
C73451-A3000-B20
C73451-A3000-C41
3
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
(4) Figure 8-3
”
(6) Figure 8-3
(8) Figure 8-2
(9) Figure 8-2
(10) Figure 8-2
--
--
Backplane module
Power supply unit -- 24 V UC
-- 115/230 V AC
Basic circuit board: S-/K-controller
Terminal: -- 4-pole
-- 8-pole
-- 3-pole
Mains plug:
-- 3-pin plug for
115/230 V AC IEC--230/V, DIN 49457A
-- Special 2-pin plug for 24 V UC
without mains plug C73451-A3004-B8
C73451-A3004-B5
C73451-A3004-L105
W73078-B1003-A904
W73078-B1017-A908
W73078-B1018-A903
C73334-Z343-C3
C73334-Z343-C6
4
4.1
4.2
4.3
4.4
--
--
--
--
--
Options
Terminals:
-- 4-pin for 6DR2800-8J/8R
-- 4-pin for 6DR2800-8V
-- 5-pin for 6DR2801-8C
-- 6-pin for 6DR2801-8D/8E
see chapter 8.5,
Ordering data
W73078-B1001-A904
W73078-B1003-A904
W73078-B1001-A705
W73078-B1001-A906
D Ordering information
The order must contain:
- Quantity
- Order number
- Description
We recommend you to specify the controller order number to be on the safe side.
D Ordering example
2 units W73078-B1003-A904
Terminal 4-pin backplane module DR21
