7 Application examples for configuring the controller
7.4 Configuring tool, forms
Manual
216
SIPART DR21
C73000-B7476-C143-08
7.4 Configuring tool, forms
We recommend the following procedure for solving your controller problems:
- Determining the assembly of the controller
- If necessary: Determining the position of bridges and switches on the backplane module and
signal transformers
- Drawing the wiring diagram
- Enter settings further down in the onPA, ofPA and Stru list (structuring, parameterizing)
- The SIMATIC PDM program is available for PC-supported configurations.
