Siemens SIPART DR21 User Manual

3 Functional description of the structure switches
3.3 Digital input signal processing (S23 to S41)
Manual
54
SIPART DR21
C73000-B7476-C143-08
D Functional explanation of the control signals
CB Computer-standby
Depending on the controller type this digital signal together with the
Internal/External key effects either switching in the setpoint range or
DDC-operation begins. Central computer-fail-line in SPC and DDC-operation.
He Manual external
This signal blocks the output of the controller and enables direct manual
adjustment of the manipulated variable on the front control panel.
N Tracking
With this signal the output of the K-controller and the three-position-stepper
controller with external position feedback is tracked to the tracking signal y
N
.
Si Safety operation
In K-controllers and three-position-stepper controllers with external position
feedback, the manipulated variable adopts the parameterized safety value. In
three-position-stepper controllers with internal feedback the manipulated
variable runs independently of the safety setting value to a defined limit
position.
bLS Blocking structuring
The whole configuration is blocked with the exception of the online
parameterization level.
bLPS Blocking parameterization and structuring
The entire configuring of the instrument is blocked, this means the
parameterization as well. Only the normal process operation according to the
preselected controller type is permitted.
bLb Blocking operation
This signal blocks the entire front panel operation of the instrument.
P P-Operation controller
With this signal the controller is switched to P-operation.
tS
setpoint ramp
The set setpoint ramp time can be made ineffective with this signal
(tS
= High ≙ ramp switched off).
tSH setpoint hold (setpoint ramp)
The setpoint change is stopped with this signal. The setpoint change continues
when the signal is reset.
yBL Direction-dependent blocking of the manipulated variable
Direction-dependent limiting of the manipulated variable by external signals,
e.g. from the limit switches of the actuating drives. This limiting is effective in
every operating mode.
