Siemens SIPART DR21 User Manual

9 General explanation of abbreviations for SIP ART DRManual
SIPART DR21
C73000-B7476-C143-08
229
9 General explanation of abbreviations for SIPART DR
A control signal no automatic mode.................
A* Parameter Alarms (limit values)................
Ad.................
AdAP Parameterization mode Adaptation.............
AdAPT LED, adaptation mode............
AH* Response threshold (dead zone)..............
AI* Analog inputs...............
AI*A Outputs of the analog inputs..............
AO Analog output...............
APSt Structuring mode All Preset (whole controller to factory setting).............
AUto automatic..............
Ar* Function block, Arithmetic...............
bLb Control signal, Blocking, Operating...............
bLPS Control signal, Blocking, Parameterization/Structuring.............
bLPS
DI
Control signal, Blocking, Parameterization/Structuring via digital input............
bLPS
ES
Control signal, Blocking, Parameterization/Structuring via SES...........
bLS Control signal, Blocking, Structuring..............
bLS
DI
Control signal, Blocking, Structuring via digital input.............
bLS
ES
Control signal, Blocking, Structuring via SES............
c* Parameter, Constants................
C
LED, no computer standby.................
CA Calibration, start of range...............
CAE3 Parameterization mode, UNI-module.............
CB Control signal, Computer operation...............
CB
DI
Control signal, Computer operation via digital inputs..............
CB
ES
Control signal, Computer operation via SES.............
cP (Kp) Proportional action factor................
CPU central processing unit..............
Cr Calibration, adjustment of line resistances (R
L
)................
dA Parameter, display range, start................
DDC direct digital control..............
dE Parameter, display range, end................
DI** Digital inputs..............
DO** Digital outputs.............
dP Parameter , display decimal point................
dPv Parameter direction of step command...............
dr Parameter, display refresh rate................
dY Parameter amplitude of the step command................
Ed.................
End Error message end..............
