2 Technical Description
2.6 Technical Data
Manual
SIPART DR21
C73000-B7476-C143-08
37
Digital inputs DI1, DI2
Signal status 0 4.5 V or open
Signal status 1 13 V
Input resistance 27 kΩ
Static destruction limit 35 V
.
NOTE
All error specifications refer to the rated signal range
Analog outputs AO
Rated signal range (0 to 100 %) 0 to 20 mA or 4 to 20 mA
Modulation range 0 to 20.5 mA or 3.8 to 20.5 mA
Load voltage from --1 to 18 V
No-load voltage 26 V
Inductive load 0.1 H
T ime constant 10 ms
Residual ripple 900 Hz 0.2 %
Resolution 0.1 %
Load dependence 0.1 %
Zero error 0.3 %
1)
Full scale error 0.3 %
1)
Linearity 0.05 %
Temperature influence
Zero point
Full scale
0.1%/10K
0.1%/10K
Static destruction limit --1 to 35 V
S-output (relay 230 V) DO7 and DO8
- Contact material Ag / Ni
- Contact load capacity
Switching voltage
AC
DC
250 V
250 V
Switching current Contacts Contacts
locked
unlocked
AC
DC
8A 2.5 A
8A 2.5 A
Rating
AC
DC
1250 VA
30 W at 250 V
100 W at 24 V
1)
Applies for interference acc. to IEC 801-3 to 3 V/m, with 10 V/m at 290 to 310 MHz 4.3 %
