2 Functions
112
7UM61 Manual
C53000-G1176-C127-3
2.17.4 Information List
4209 f3 PICKUP 40.00 .. 65.00 Hz 59.50 Hz f3 Pickup
4210 T f3 0.00 .. 100.00 sec 20.00 sec T f3 Time Delay
4211 f4 PICKUP 40.00 .. 65.00 Hz 52.00 Hz f4 Pickup
4212 f4 PICKUP 40.00 .. 65.00 Hz 62.00 Hz f4 Pickup
4213 T f4 0.00 .. 100.00 sec 10.00 sec T f4 Time Delay
4214 THRESHOLD f4 automatic
f>
f<
automatic Handling of Threshold Stage f4
4215 Umin 10.0 .. 125.0 V; 0 65.0 V Minimum Required Voltage for
Operation
No. Information Type of In-
formation
Comments
5203 >BLOCK Freq. EM >BLOCK frequency protection
5206 >BLOCK f1 EM >BLOCK stage f1
5207 >BLOCK f2 EM >BLOCK stage f2
5208 >BLOCK f3 EM >BLOCK stage f3
5209 >BLOCK f4 EM >BLOCK stage f4
5211 Freq. OFF AM Frequency protection is OFF
5212 Freq. BLOCKED AM Frequency protection is BLOCKED
5213 Freq. ACTIVE AM Frequency protection is ACTIVE
5214 Freq UnderV Blk AM Frequency protection undervoltage Blk
5232 f1 picked up AM f1 picked up
5233 f2 picked up AM f2 picked up
5234 f3 picked up AM f3 picked up
5235 f4 picked up AM f4 picked up
5236 f1 TRIP AM f1 TRIP
5237 f2 TRIP AM f2 TRIP
5238 f3 TRIP AM f3 TRIP
5239 f4 TRIP AM f4 TRIP
Addr. Parameter Setting Options Default Setting Comments
