Siemens Siprotec 7UM611 User Manual

2 Functions
40
7UM61 Manual
C53000-G1176-C127-3
2.5 Power System Data 2
The general protection data (P.System Data 2) include settings associated with all
functions rather than a specific protection or monitoring function. Parameter settings
P.System Data 2 can be switched using the setting group.
2.5.1 Functional Description
Setting Groups In the 7UM61 relay, two independent setting groups (A and B) are possible. Whereas
setting values may vary, the selected functions of each setting group remain the same.
2.5.2 Setting Notes
General To enter these group-specific general protection data (P.System Data 2), select in
the SETTINGS menu theGroup A (Parameter group A), and in it P.System Data
2. The other setting group is accessible under Group B.
Rated Values of the
System
At addresses 1101 U PRIMARY OP. and 1102 I PRIMARY OP., the primary refer-
ence voltage and reference current of the protected motor is entered. These values
are important for pickup settings. The allow the device to calculate operational values
as percentage values. For example, if a CT ratio of 500/1 is selected and the rated
current of the generator is 483 A, a value of 500 A should be entered at address 211
and a value of 483 A under I PRIMARY OP.. 483 amps are now displayed as 100%
in the percentage metering display.
Active Power Direc-
tion
Address 1108 ACTIVE POWER is used to specify the active power direction in the
normal mode (Generator = output or Motor = input) or to adapt it to the power
system conditions without device recabling.
2.5.3 Settings
2.5.4 Information List
Addr. Parameter Setting Options Default Setting Comments
1101 U PRIMARY OP. 0.10 .. 400.00 kV 6.30 kV Primary Operating Voltage
1102 I PRIMARY OP. 10 .. 50000 A 483 A Primary Operating Current
1108 ACTIVE POWER Generator
Motor
Generator Measurement of Active Power for
No. Information Type of In-
formation
Comments
501 Relay PICKUP AM Relay PICKUP
511 Relay TRIP AM Relay GENERAL TRIP command
533 IL1: AM Primary fault current IL1
