Siemens Siprotec 7UM611 User Manual

A Appendix
408
7UM61 Manual
C53000-G1176-C127-3
A.10 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- IL< under current (IL<) Set Points(MV) - - - - - CFC CD DD
- Number of TRIPs (#of TRIPs=) Statistics - - - - - CD DD
- Number of TRIPs (#of TRIPs=) Statistics - - - - - CD DD
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CD DD
601 I L1 (IL1 =) Measurement 134 147 No 9 1 CFC CD DD
602 I L2 (IL2 =) Measurement 134 147 No 9 2 CFC CD DD
603 I L3 (IL3 =) Measurement 134 147 No 9 3 CFC CD DD
605 I1 (positive sequence) (I1 =) Measurement 134 147 No 9 5 CFC CD DD
606 I2 (negative sequence) (I2 =) Measurement 134 147 No 9 6 CFC CD DD
621 U L1-E (UL1E=) Measurement 134 147 No 9 7 CFC CD DD
622 U L2-E (UL2E=) Measurement 134 147 No 9 8 CFC CD DD
623 U L3-E (UL3E=) Measurement 134 147 No 9 9 CFC CD DD
624 U L12 (UL12=) Measurement - - - - - CFC CD DD
625 U L23 (UL23=) Measurement - - - - - CFC CD DD
626 U L31 (UL31=) Measurement - - - - - CFC CD DD
627 Displacement voltage UE (UE =) Measurement 134 147 No 9 10 CFC CD DD
629 U1 (positive sequence) (U1 =) Measurement 134 147 No 9 11 CFC CD DD
630 U2 (negative sequence) (U2 =) Measurement - - - - - CFC CD DD
639 UE 3rd Harmonic Voltage Minimum (UE3h
Min=)
Min/Max meter - - - - - CFC CD DD
640 UE 3rd Harmonic Voltage Maximum (UE3h
Max=)
Min/Max meter - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 147 No 9 12 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 147 No 9 13 CFC CD DD
644 Frequency (Freq=) Measurement 134 147 No 9 15 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
650 UE 3rd harmonic (UE3h=) Measurement - - - - - CFC CD DD
660 Remaining Time for Switch ON (T Rem.=) Meas. Thermal - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ REST. =) Meas. Thermal - - - - - CFC CD DD
765 (U/Un) / (f/fn) (U/f =) Measurement 134 147 No 9 16 CFC CD DD
766 Calculated temperature (U/f) (U/f th. =) Meas. Thermal - - - - - CFC CD DD
801 Temperat. rise for warning and trip (Θ/Θtrip
=)
Meas. Thermal - - - - - CFC CD DD
802 Temperature rise for phase L1 (Θ/ΘtripL1=) Meas. Thermal - - - - - CFC CD DD
803 Temperature rise for phase L2 (Θ/ΘtripL2=) Meas. Thermal - - - - - CFC CD DD
804 Temperature rise for phase L3 (Θ/ΘtripL3=) Meas. Thermal - - - - - CFC CD DD
805 Temperature of Rotor (ΘR/ΘRmax =) Meas. Thermal - - - - - CFC CD DD
830 Senstive Earth Fault Current (IEE =) Measurement 134 147 No 9 4 CFC CD DD
831 3I0 (zero sequence) (3I0 =) Measurement - - - - - CFC CD DD
832 U0 (zero sequence) (U0 =) Measurement - - - - - CFC CD DD
857 Positive Sequence Minimum (I1Min=) Min/Max meter - - - - - CFC CD DD
858 Positive Sequence Maximum (I1Max=) Min/Max meter - - - - - CFC CD DD
874 U1 (positive sequence) Voltage Minimum
(U1Min=)
Min/Max meter - - - - - CFC CD DD
875 U1 (positive sequence) Voltage Maximum
(U1Max=)
Min/Max meter - - - - - CFC CD DD
