2 Functions
190
7UM61 Manual
C53000-G1176-C127-3
2.31.3 Settings
2.31.4 Information List
Addr. Parameter Setting Options Default Setting Comments
8601 EXTERN TRIP 1 OFF
ON
Block relay
OFF External Trip Function 1
8602 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 1 Time Delay
8701 EXTERN TRIP 2 OFF
ON
Block relay
OFF External Trip Function 2
8702 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 2 Time Delay
8801 EXTERN TRIP 3 OFF
ON
Block relay
OFF External Trip Function 3
8802 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 3 Time Delay
8901 EXTERN TRIP 4 OFF
ON
Block relay
OFF External Trip Function 4
8902 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 4 Time Delay
No. Information Type of In-
formation
Comments
4523 >BLOCK Ext 1 EM >Block external trip 1
4526 >Ext trip 1 EM >Trigger external trip 1
4531 Ext 1 OFF AM External trip 1 is switched OFF
4532 Ext 1 BLOCKED AM External trip 1 is BLOCKED
4533 Ext 1 ACTIVE AM External trip 1 is ACTIVE
4536 Ext 1 picked up AM External trip 1: General picked up
4537 Ext 1 Gen.TRP AM External trip 1: General TRIP
4543 >BLOCK Ext 2 EM >BLOCK external trip 2
4546 >Ext trip 2 EM >Trigger external trip 2
4551 Ext 2 OFF AM External trip 2 is switched OFF
4552 Ext 2 BLOCKED AM External trip 2 is BLOCKED
4553 Ext 2 ACTIVE AM External trip 2 is ACTIVE
4556 Ext 2 picked up AM External trip 2: General picked up
4557 Ext 2 Gen.TRP AM External trip 2: General TRIP
4563 >BLOCK Ext 3 EM >BLOCK external trip 3
4566 >Ext trip 3 EM >Trigger external trip 3
4571 Ext 3 OFF AM External trip 3 is switched OFF
4572 Ext 3 BLOCKED AM External trip 3 is BLOCKED
4573 Ext 3 ACTIVE AM External trip 3 is ACTIVE
4576 Ext 3 picked up AM External trip 3: General picked up
4577 Ext 3 Gen.TRP AM External trip 3: General TRIP
4583 >BLOCK Ext 4 EM >BLOCK external trip 4
