2.1 Introduction, Reference Systems
29
7UM61 Manual
C53000-G1176-C127-3
2.1 Introduction, Reference Systems
The following chapters explain the individual protective and additional functions and
provide information about the setting values.
2.1.1 Functional Description
Generator The calculation examples are based on two smaller capacity reference power systems
with the two typical basic connections, i.e. the busbar connection and the unit connec-
tion (see following figure). All default settings of the relay are adapted accordingly.
Figure 2-1 Reference Systems
