2 Functions
122
7UM61 Manual
C53000-G1176-C127-3
2.19.4 Information List
4517 df4/dt & f4 OFF
ON
OFF AND logic with pickup of stage f4
4518 U MIN 10.0 .. 125.0 V; 0 65.0 V Minimum Operating Voltage Umin
4519A df1/2 HYSTERES. 0.02 .. 0.99 Hz/s 0.10 Hz/s Reset Hysteresis for df1/dt &
df2/dt
4520A df1/2 M-WINDOW 1 .. 25 Cycle 5 Cycle Measuring Window for df1/dt &
df2/dt
4521A df3/4 HYSTERES. 0.02 .. 0.99 Hz/s 0.40 Hz/s Reset Hysteresis for df3/dt &
df4/dt
4522A df3/4 M-WINDOW 1 .. 25 Cycle 5 Cycle Measuring Window for df3/dt &
df4/dt
No. Information Type of In-
formation
Comments
5503 >df/dt block EM >BLOCK Rate-of-frequency-change prot.
5504 >df1/dt block EM >BLOCK df1/dt stage
5505 >df2/dt block EM >BLOCK df2/dt stage
5506 >df3/dt block EM >BLOCK df3/dt stage
5507 >df4/dt block EM >BLOCK df4/dt stage
5511 df/dt OFF AM df/dt is switched OFF
5512 df/dt BLOCKED AM df/dt is BLOCKED
5513 df/dt ACTIVE AM df/dt is ACTIVE
5514 df/dt U< block AM df/dt is blocked by undervoltage
5516 df1/dt pickup AM Stage df1/dt picked up
5517 df2/dt pickup AM Stage df2/dt picked up
5518 df3/dt pickup AM Stage df3/dt picked up
5519 df4/dt pickup AM Stage df4/dt picked up
5520 df1/dt TRIP AM Stage df1/dt TRIP
5521 df2/dt TRIP AM Stage df2/dt TRIP
5522 df3/dt TRIP AM Stage df3/dt TRIP
5523 df4/dt TRIP AM Stage df4/dt TRIP
Addr. Parameter Setting Options Default Setting Comments
