37UM61 Manual
C53000-G1176-C127-3
Preface
Purpose of this
Manual
This manual describes the functions, operation, installation, and commissioning of the
device 7UM61. In particular it contains:
• Information regarding the configuration of the device extent and descriptions of
device functions and settings → Chapter 2;
• Instructions for mounting and commissioning → Chapter 3;
• Compilation of technical data→ Chapter 4;
• As well as a compilation of the most significant data for experienced users in Ap-
pendix A.
General information about design, configuration, and operation of SIPROTEC
®
4
devices is laid down in the SIPROTEC
®
System Description /1/.
Target Audience Protection engineers, commissioning engineers, personnel concerned with adjust-
ment, checking, and service of selective protective equipment, automatic and control
facilities, and personnel of electrical facilities and power plants.
Applicability of this
Manual
This manual is valid for: Multi-Functional Generator Protection Relay with Local
Control SIPROTEC
®
4 7UM61; firmware version V4.1.
Indication of Con-
formity
This product is UL-certified according to the Technical Data:
This product complies with the directive of the Council of the European Commu-
nities on the approximation of the laws of the Member States relating to electro-
magnetic compatibility (EMC Council Directive 89/336/EEC) and concerning elec-
trical equipment for use within specified voltage limits (Low-voltage directive 73/23
EEC).
This conformity has been proved by tests conducted by Siemens AG in accor-
dance with Article 10 of the Council Directive in agreement with the generic stan-
dards EN 50081 and EN 61000-6-2 (for EMC directive) and the standard
EN 60255-6 (for low-voltage directive). This device was designed and produced
for industrial use according to the EMC standard.
The product conforms with the international standard of the series IEC 60255 and
the German standard VDE 0435.
