4.1 General
305
7UM61 Manual
C53000-G1176-C127-3
4.1.9 Certifications
4.1.10 Construction
UL Listing UL recognition
7UM61**–*B***–****
Models with screw ter-
minals
7UM61**–*B***–****
Models with plug–in
terminals
7UM61**–*B***–****
Case 7XP20
Dimensions See dimensional drawings, Section 4.26
Weight approx.
in flush mounting, housing size 1/3 about 12 pounds (5.5 kg)
in flush mounting, housing size 1/2 about 12 pounds (7 kg)
in surface mounting, housing size 1/3 about 17 pounds (7.5 kg)
in surface mounting, housing size 1/2 about 27 pounds (12 kg)
Protection class acc. to IEC 60 529
for surface mounting case equipment IP 51
in flush mounted case
Front IP 51
Rear IP 50
for personnel protection IP 2x with cover in place
