4 Technical Data
296
7UM61 Manual
C53000-G1176-C127-3
AC Voltage
4.1.3 Binary Inputs and Outputs
Binary Inputs
7UM611 energized approx. 9.5 W
7UM612 approx. 12.5 W
Bridging time on failure or short circuit ≥ 50 ms at V ≥ 110 V DC
≥ 20 ms at V ≥ 24 V DC
Voltage supply using integrated converter
Nominal Auxiliary AC Voltage U
Aux
115 VAC (50/60 Hz) 230 V AC (50/60 Hz)
admissible voltage ranges 92 to 132 V AC 184 to 265 V AC
Quiescent power consumption approx. 4 VA
Quiescent power consumption approx. 12 VA
Bridging time on failure or short circuit ≥ 200 ms
Variant Number
7UM611*– 7 (configurable)
7UM612*– 15 (configurable)
Rated Voltage Range 24 V DC to 250 V DC, bipolar
Current Consumption, Energized approx. 1.8 mA, independent of control voltage
Switching Thresholds adjustable with jumpers
Binary Inputs BI1 to BI7
for rated voltages 24/48/
60/110/125 V DC
U
high
≥ 19 V DC
U
low
≤ 10 V DC
for rated voltages 110/125/
220/250 V DC
U
high
≥ 88 V DC
U
low
≤ 44 V DC
Binary Inputs BI8 to BI15
for rated voltages 24/48/
60/110/125 V DC
U
high
≥ 19 V DC
U
low
≤ 10 V DC
for rated voltages 110/125/
220/250 V DC
U
high
≥ 88 V DC
U
low
≤ 44 V DC
for rated voltages 220/250 V DC U
high
≥ 176 V DC
U
low
≤ 88 V DC
Maximum admissible voltage 300 V DC
Input Impulse suppression 220 nF coupling capacity at 220 V with recovery
time > 60 ms
