A Appendix
374
7UM61 Manual
C53000-G1176-C127-3
A.4.3 Binary Output
Table A-3 Output relay presettings for all devices and ordering variants
1)
Only for 7UM612
2)
Generator Circuit Breaker
3)
De-excitation
4)
Emergency Tripping
Binary Output Short Text Function No. Description
BO1 Error PwrSupply 147 Error Power Supply
Fail Battery 177 Failure: Battery empty
BO2 Relay TRIP 511 Relay GENERAL TRIP command
BO3 List Empty - -
BO4 ... 11 List Empty - -
1
BO12 I> TRIP 1815 O/C I> TRIP
BO13 IEE> TRIP 1226 IEE> TRIP
U0> TRIP 5187 Stator earth fault: U0 stage TRIP
S/E/F TRIP 5193 Stator earth fault protection TRIP
BO14 U< TRIP 6539 Undervoltage U< TRIP
U> TRIP 6570 Overvoltage U> TRIP
U>> TRIP 6573 Overvoltage U>> TRIP
BO15 f1 TRIP 5236 f1 TRIP
f2 TRIP 5237 f2 TRIP
BO16 Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
BO17 f1 TRIP 5236 f1 TRIP
2
f2 TRIP 5237 f2 TRIP
2
I> TRIP 1815 O/C I> TRIP
2
U>> TRIP 6573 Overvoltage U>> TRIP
2
Pr TRIP 5097 Reverse power: TRIP
2
Pr+SV TRIP 5098 Reverse power: TRIP with stop
valve
2
S/E/F TRIP 5193 Stator earth fault protection TRIP
2
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal
stage
2
Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
2
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
2
BO18 f2 TRIP 5237 f2 TRIP
3
I> TRIP 1815 O/C I> TRIP
3
U>> TRIP 6573 Overvoltage U>> TRIP
3
Pr+SV TRIP 5098 Reverse power: TRIP with stop
valve
3
S/E/F TRIP 5193 Stator earth fault protection TRIP
3
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal
stage
3
Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
3
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
3
BO19 f2 TRIP 5237 f2 TRIP
4
I> TRIP 1815 O/C I> TRIP
4
S/E/F TRIP 5193 Stator earth fault protection TRIP
4
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal
stage
4
