4.22 Inadvertent Energization (ANSI 50, 27)
Setting Ranges / Increments
Times
Dropout Ratios
Tolerances
Influencing Variables for Pickup Values
Pickup Current I>>> for I
N
= 1 A 0.1 A to 20.0 A Increments
0.1 A
for I
N
= 5 A 0.5 A to 20.0 A Increments
0.5 A
or ∞ (ineffective)
Tripping Enabling U
1
< 10.0 V to 125.0 V
or 0 V (no enable)
Increments 0.1V
Delay time T U
1
<PICKUP 0.00 s to 60.00 s
or ∞ (ineffective)
Increments 0.01
s
Dropout time T U
1
<DROPOUT 0.00 s to 60.00 s
or ∞ (ineffective)
Increments 0.01
s
Response time approx. 25 ms
Dropout Time approx. 35 ms
I>>> for I
N
= 1 A Approx. 0.80 or 50 mA
for I
N
= 5 A Approx. 0.80 or 250 mA
Tripping enabling U1< approx. 1.05
Pickup Current I>>> for I
N
= 1 A 5 % of setting value or 20 mA
for I
N
= 5 A 5 % of setting value or 100 mA
Tripping Enabling U
1
< 1 % of setting value or 0.5 V
Delay Time T 1 % or 10 ms
Power Supply DC Voltage in Range
0,8 ≤ U
PS
/U
PSN
≤ 1.15
≤ 1 %
Temperature in Range
–5 °C ≤ Θ
amb
≤ 55 °C
≤ 0.5 % / 10 K
Frequency in Range
0,95 ≤ f/f
N
≤ 1.05
≤ 1 %
Harmonics
– Up to 10 % 3rd harmonic
– Up to 10 % 5th harmonic
≤ 1 %
≤ 1 %
