2 Functions
88
7UM61 Manual
C53000-G1176-C127-3
2.12.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
2.12.4 Information List
Addr. Parameter Setting Options Default Setting Comments
3101 REVERSE POWER OFF
ON
Block relay
OFF Reverse Power Protection
3102 P> REVERSE -30.00 .. -0.50 % -1.93 % P> Reverse Pickup
3103 T-SV-OPEN 0.00 .. 60.00 sec; ∞ 10.00 sec Time Delay Long (without Stop
Valve)
3104 T-SV-CLOSED 0.00 .. 60.00 sec; ∞ 1.00 sec Time Delay Short (with Stop
Valve)
3105A T-HOLD 0.00 .. 60.00 sec; ∞ 0.00 sec Pickup Holding Time
No. Information Type of In-
formation
Comments
5083 >Pr BLOCK EM >BLOCK reverse power protection
5086 >SV tripped EM >Stop valve tripped
5091 Pr OFF AM Reverse power prot. is switched OFF
5092 Pr BLOCKED AM Reverse power protection is BLOCKED
5093 Pr ACTIVE AM Reverse power protection is ACTIVE
5096 Pr picked up AM Reverse power: picked up
5097 Pr TRIP AM Reverse power: TRIP
5098 Pr+SV TRIP AM Reverse power: TRIP with stop valve
