2 Functions
58
7UM61 Manual
C53000-G1176-C127-3
2.8.4 Information List
1407 VOLT. INFLUENCE without
Volt. controll.
Volt. restraint
without Voltage Influence
1408 U< 10.0 .. 125.0 V 75.0 V U< Threshold for Release
Ip
No. Information Type of In-
formation
Comments
1883 >BLOCK O/C Ip EM >BLOCK inverse O/C time protection
1891 O/C Ip OFF AM O/C protection Ip is switched OFF
1892 O/C Ip BLOCKED AM O/C protection Ip is BLOCKED
1893 O/C Ip ACTIVE AM O/C protection Ip is ACTIVE
1896 O/C Ip Fault L1 AM O/C fault detection Ip phase L1
1897 O/C Ip Fault L2 AM O/C fault detection Ip phase L2
1898 O/C Ip Fault L3 AM O/C fault detection Ip phase L3
1899 O/C Ip pick.up AM O/C Ip picked up
1900 O/C Ip TRIP AM O/C Ip TRIP
Addr. Parameter C Setting Options Default Setting Comments
