A.10 Measured Values
409
7UM61 Manual
C53000-G1176-C127-3
â–
876 Active Power Minimum (PMin=) Min/Max meter - - - - - CFC CD DD
877 Active Power Maximum (PMax=) Min/Max meter - - - - - CFC CD DD
878 Reactive Power Minimum (QMin=) Min/Max meter - - - - - CFC CD DD
879 Reactive Power Maximum (QMax=) Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fMin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fMax=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy - - - - - CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy - - - - - CD DD
901 Power Factor (PF =) Measurement 134 147 No 9 14 CFC CD DD
902 Power angle (PHI =) Measurement - - - - - CFC CD DD
903 Resistance (R =) Measurement - - - - - CFC CD DD
904 Reactance (X =) Measurement - - - - - CFC CD DD
910 Calculated rotor temp. (unbal. load) (Therm-
Rep.=)
Meas. Thermal - - - - - CFC CD DD
911 Cooling medium temperature (AMB.TEMP =) Meas. Thermal - - - - - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CD DD
924 Wp Forward (Wp+=) Energy - - - - - CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CD DD
925 Wq Forward (Wq+=) Energy - - - - - CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CD DD
928 Wp Reverse (Wp-=) Energy - - - - - CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CD DD
929 Wq Reverse (Wq-=) Energy - - - - - CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Meas. Thermal 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Meas. Thermal 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Meas. Thermal 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Meas. Thermal 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Meas. Thermal 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Meas. Thermal 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Meas. Thermal 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Meas. Thermal 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Meas. Thermal 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10 =) Meas. Thermal 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11 =) Meas. Thermal 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12 =) Meas. Thermal 134 146 No 9 12 CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
