Siemens Siprotec 7UM611 User Manual

2 Functions
198
7UM61 Manual
C53000-G1176-C127-3
9092A RTD 9 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 9: Location
9093 RTD 9 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 9: Temperature Stage 1
Pickup
9094 RTD 9 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 9: Temperature Stage 1
Pickup
9095 RTD 9 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 9: Temperature Stage 2
Pickup
9096 RTD 9 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 9: Temperature Stage 2
Pickup
9101A RTD10 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD10: Type
9102A RTD10 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD10: Location
9103 RTD10 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD10: Temperature Stage 1
Pickup
9104 RTD10 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD10: Temperature Stage 1
Pickup
9105 RTD10 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD10: Temperature Stage 2
Pickup
9106 RTD10 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD10: Temperature Stage 2
Pickup
9111A RTD11 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD11: Type
9112A RTD11 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD11: Location
9113 RTD11 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD11: Temperature Stage 1
Pickup
9114 RTD11 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD11: Temperature Stage 1
Pickup
9115 RTD11 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD11: Temperature Stage 2
Pickup
9116 RTD11 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD11: Temperature Stage 2
Pickup
Addr. Parameter Setting Options Default Setting Comments
