Siemens Siprotec 7UM611 User Manual

4 Technical Data
300
7UM61 Manual
C53000-G1176-C127-3
Profibus FO (FMS and DP)
Fibre optic connector type ST-connector single ring / double ring
according to the order for FMS; for DP
only double ring available
Connection for flush-
mounted case
rear panel, mounting location "B"
for surface-mounted case in console housing at case bottom
Transmission Speed up to 1.5 MBd
recommended: > 500 kBd
optical wavelength λ = 820 nm
Laser Class 1 according to
EN 60825–1/–2
Using glass fibre 50/125 µm or using
glass fibre 62.5/125 µm
admissible link signal at-
tenuation
max. 8 dB, with glass fibre
62.5/125 µm
bridgeable distance max. 1.5 km (0.94 miles)
DNP3.0 Fibre Optical Link
Fibre optic connector type ST connector transmitter/receiver
Connection for flush-
mounted case
rear panel, mounting location "B"
for surface-mounted case in console housing at case bottom
Transmission Speed up to 19,200 Bd
optical wavelength λ = 820 nm
Laser Class 1 according to
EN 60825–1/–2
Using glass fibre 50/125 µm or using
glass fibre 62.5/125µm
admissible link signal at-
tenuation
max. 8 dB, with glass fibre
62.5/125 µm
bridgeable distance max. 1.5 km (0.94 miles)
MODBUS Fibre Optical
Link
Fibre optic connector type ST connector transmitter/receiver
Connection for flush-
mounted case
rear panel, mounting location "B"
for surface-mounted case in console housing at case bottom
Transmission Speed up to 19,200 Bd
optical wavelength λ = 820 nm
Laser Class 1 according to
EN 60825-1/-2
Using glass fibre 50/125 µm or using
glass fibre 62.5/125 µm
admissible link signal at-
tenuation
max. 8 dB, with glass fibre
62.5/125 µm
bridgeable distance max. 1.5 km (0.94 miles)
