A.1 Ordering Information and Accessories
355
7UM61 Manual
C53000-G1176-C127-3
Short-circuit links Short circuit jumpers for terminal type Order No.
Voltage terminal, 18-pole terminal, or 12-pole terminal C73334-A1-C34-1
Current terminal,12-pole terminal, or 8-pole terminal C73334-A1-C33-1
Socket housing
Socket housing Order No.
2-pole C73334-A1-C35-1
3-pole C73334-A1-C36-1
Angle brackets for
mounting in 19"-
racks
Name Order No.
Angle Strip (Mounting Rail) C73165-A63-C200-3
Battery
Lithium battery 3 V/1 Ah, type CR 1/2 AA Order No.
VARTA 6127 101 501
Coupling unit
Coupling unit for
rotor earth fault protection Order No.
Coupling unit 7XR6100-0CA00
Series Resistor
Series resistor for rotor earth fault protection Order No.
Series resistor (2 x 105 Ω ) 3PP1336-0DZ-013002
Voltage divider
Voltage divider Order No.
Voltage divider 5:1; 5:2 3PP1336-1CZ-013001
Voltage divider 10:1; 20:1 3PP1326-0BZ-012009
Interface Cable
Interface cable between PC and SIPROTEC device Order No.
Cable with 9-pole male/female connector 7XV5100-4
Operating Software
DIGSI® 4
Protection operating and configuration software DIGSI® 4 Order No.
DIGSI® 4, basic version with license for 10 computers 7XS5400-0AA00
DIGSI® 4, complete version with all option packages 7XS5402-0AA0
Graphical analysis
program SIGRA
Graphical analysis program SIGRA® Order No.
Full version with license for 10 computers 7XS5410-0AA0
