A.6 Functional Scope
379
7UM61 Manual
C53000-G1176-C127-3
166 RESTART INHIBIT Disabled
Enabled
Enabled Restart Inhibit for Motors
170 BREAKER FAILURE Disabled
Enabled
Enabled Breaker Failure Protection
171 INADVERT. EN. Disabled
Enabled
Enabled Inadvertent Energisation
180 FUSE FAIL MON. Disabled
Enabled
Enabled Fuse Failure Monitor
181 M.V. SUPERV Disabled
Enabled
Enabled Measured Values Supervision
182 Trip Cir. Sup. Disabled
2 Binary Inputs
1 Binary Input
Disabled Trip Circuit Supervision
185 THRESHOLD Disabled
Enabled
Enabled Threshold Supervision
186 EXT. TRIP 1 Disabled
Enabled
Enabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Enabled External Trip Function 2
188 EXT. TRIP 3 Disabled
Enabled
Enabled External Trip Function 3
189 EXT. TRIP 4 Disabled
Enabled
Enabled External Trip Function 4
190 RTD-BOX INPUT Disabled
Port C
Port D
Port E
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
Addr. Parameter Setting Options Default Setting Comments
