A.7 Settings
381
7UM61 Manual
C53000-G1176-C127-3
1202 I> O/C Prot. I> 1A 0.05 .. 20.00 A 1.35 A I> Pickup
5A 0.25 .. 100.00 A 6.75 A
1203 T I> O/C Prot. I> 0.00 .. 60.00 sec; ∞ 3.00 sec T I> Time Delay
1204 U< SEAL-IN O/C Prot. I> ON
OFF
OFF State of Undervoltage Seal-in
1205 U< O/C Prot. I> 10.0 .. 125.0 V 80.0 V Undervoltage Seal-in Pickup
1206 T-SEAL-IN O/C Prot. I> 0.10 .. 60.00 sec 4.00 sec Duration of Undervoltage Seal-in
1207A I> DOUT RATIO O/C Prot. I> 0.90 .. 0.99 0.95 I> Drop Out Ratio
1301 O/C I>> O/C Prot. I>> OFF
ON
Block relay
OFF Overcurrent Time Protection I>>
1302 I>> O/C Prot. I>> 1A 0.05 .. 20.00 A 4.30 A I>> Pickup
5A 0.25 .. 100.00 A 21.50 A
1303 T I>> O/C Prot. I>> 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
1304 Phase Direction O/C Prot. I>> Forward
Reverse
Reverse Phase Direction
1305 LINE ANGLE O/C Prot. I>> -90 .. 90 ° 60 ° Line Angle
1401 O/C Ip O/C Prot. Ip OFF
ON
Block relay
OFF Inverse O/C Time Protection Ip
1402 Ip O/C Prot. Ip 1A 0.10 .. 4.00 A 1.00 A Ip Pickup
5A 0.50 .. 20.00 A 5.00 A
1403 T Ip O/C Prot. Ip 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
1404 TIME DIAL: TD O/C Prot. Ip 0.50 .. 15.00 ; ∞ 5.00 TIME DIAL: TD
1405 IEC CURVE O/C Prot. Ip Normal Inverse
Very Inverse
Extremely Inv.
Normal Inverse IEC Curve
1406 ANSI CURVE O/C Prot. Ip Very Inverse
Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1407 VOLT. INFLUENCE O/C Prot. Ip without
Volt. controll.
Volt. restraint
without Voltage Influence
1408 U< O/C Prot. Ip 10.0 .. 125.0 V 75.0 V U< Threshold for Release Ip
1601 Ther. OVER LOAD Therm. Overload OFF
ON
Block relay
Alarm Only
OFF Thermal Overload Protection
1602 K-FACTOR Therm. Overload 0.10 .. 4.00 1.11 K-Factor
1603 TIME CONSTANT Therm. Overload 30 .. 32000 sec 600 sec Thermal Time Constant
1604 Θ ALARM Therm. Overload 70 .. 100 % 90 % Thermal Alarm Stage
1605 TEMP. RISE I Therm. Overload 40 .. 200 °C100°C Temperature Rise at Rated Sec.
Curr.
1606 TEMP. RISE I Therm. Overload 104 .. 392 °F212°F Temperature Rise at Rated Sec.
Curr.
1607 TEMP. INPUT Therm. Overload Disabled
Fieldbus
RTD 1
Disabled Temperature Input
1608 TEMP. SCAL. Therm. Overload 40 .. 300 °C100°C Temperature for Scaling
1609 TEMP. SCAL. Therm. Overload 104 .. 572 °F212°F Temperature for Scaling
1610A I ALARM Therm. Overload 1A 0.10 .. 4.00 A 1.00 A Current Overload Alarm Setpoint
5A 0.50 .. 20.00 A 5.00 A
1612A Kτ-FACTOR Therm. Overload 1.0 .. 10.0 1.0 Kt-Factor when Motor Stops
1615A I MAX THERM. Therm. Overload 1A 0.50 .. 8.00 A 3.30 A Maximum Current for Thermal
Replica
5A 2.50 .. 40.00 A 16.50 A
1616A T EMERGENCY Therm. Overload 10 .. 15000 sec 100 sec Emergency Time
1701 UNBALANCE LOAD Unbalance Load OFF
ON
Block relay
OFF Unbalance Load Protection
Addr. Parameter Function C Setting Options Default Setting Comments
