A Appendix
404
7UM61 Manual
C53000-G1176-C127-3
6537 Undervoltage U<< picked up
(U<< picked up)
Undervoltage AM * ON
OFF
* LED BO 74 37 2 Yes
6539 Undervoltage U< TRIP (U< TRIP) Undervoltage AM * ON m LED BO 74 39 2 Yes
6540 Undervoltage U<< TRIP (U<<
TRIP)
Undervoltage AM * ON m LED BO 74 40 2 Yes
6565 Overvoltage protection switched
OFF (Overvolt. OFF)
Overvoltage AM ON
OFF
**LEDBO74651Yes
6566 Overvoltage protection is
BLOCKED (Overvolt. BLK)
Overvoltage AM ON
OFF
ON
OFF
* LED BO 74 66 1 Yes
6567 Overvoltage protection is
ACTIVE (Overvolt. ACT)
Overvoltage AM ON
OFF
**LEDBO74671Yes
6568 Overvoltage U> picked up (U>
picked up)
Overvoltage AM * ON
OFF
* LED BO 74 68 2 Yes
6570 Overvoltage U> TRIP (U> TRIP) Overvoltage AM * ON m LED BO 74 70 2 Yes
6571 Overvoltage U>> picked up (U>>
picked up)
Overvoltage AM * ON
OFF
* LED BO 74 71 2 Yes
6573 Overvoltage U>> TRIP (U>>
TRIP)
Overvoltage AM * ON m LED BO 74 73 2 Yes
6575 Voltage Transformer Fuse Failure
(VT Fuse Failure)
Measurem.Superv AM ON
OFF
**LEDBO74741Yes
6801 >BLOCK Motor Starting Supervi-
sion (>BLK START-SUP)
Start Motor EM * * * LED BI BO
6805 >Rotor is locked (>Rotor locked) Start Motor EM ON
OFF
**LEDBIBO
6811 Starting time supervision
switched OFF (START-SUP
OFF)
Start Motor AM ON
OFF
* * LED BO 169 51 1 Yes
6812 Starting time supervision is
BLOCKED (START-SUP BLK)
Start Motor AM ON
OFF
ON
OFF
*LED BO 169521Yes
6813 Starting time supervision is
ACTIVE (START-SUP ACT)
Start Motor AM ON
OFF
* * LED BO 169 53 1 Yes
6821 Starting time supervision TRIP
(START-SUP TRIP)
Start Motor AM * ON * LED BO 169 54 2 Yes
6822 Rotor is LOCKED after Locked
Rotor Time (Rotor locked)
Start Motor AM * ON * LED BO 169 55 2 Yes
6823 Starting time supervision picked
up (START-SUP PU)
Start Motor AM ON
OFF
* * LED BO 169 56 1 Yes
6851 >BLOCK Trip circuit supervision
(>BLOCK TripC)
TripCirc.Superv EM * * * LED BI BO
6852 >Trip circuit supervision: trip relay
(>TripC trip rel)
TripCirc.Superv EM ON
OFF
* * LED BI BO 170 51 1 Yes
6853 >Trip circuit supervision: breaker
relay (>TripC brk rel.)
TripCirc.Superv EM ON
OFF
* * LED BI BO 170 52 1 Yes
6861 Trip circuit supervision OFF
(TripC OFF)
TripCirc.Superv AM ON
OFF
* * LED BO 170 53 1 Yes
6862 Trip circuit supervision is
BLOCKED (TripC BLOCKED)
TripCirc.Superv AM ON
OFF
ON
OFF
*LED BO 153161Yes
6863 Trip circuit supervision is ACTIVE
(TripC ACTIVE)
TripCirc.Superv AM ON
OFF
* * LED BO 153 17 1 Yes
6864 Trip Circuit blk. Bin. input is not
set (TripC ProgFail)
TripCirc.Superv AM ON
OFF
* * LED BO 170 54 1 Yes
6865 Failure Trip Circuit (FAIL: Trip cir.) TripCirc.Superv AM ON
OFF
* * LED BO 170 55 1 Yes
7960 Measured Value MV1> picked up
(Meas. Value1>)
Threshold AM * * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
