A Appendix
406
7UM61 Manual
C53000-G1176-C127-3
14182 RTD 8 Temperature stage 1
picked up (RTD 8 St.1 p.up)
RTD-Box AM ON
OFF
**LEDBO
14183 RTD 8 Temperature stage 2
picked up (RTD 8 St.2 p.up)
RTD-Box AM ON
OFF
**LEDBO
14191 Fail: RTD 9 (broken wire/shorted)
(Fail: RTD 9)
RTD-Box AM ON
OFF
**LEDBO
14192 RTD 9 Temperature stage 1
picked up (RTD 9 St.1 p.up)
RTD-Box AM ON
OFF
**LEDBO
14193 RTD 9 Temperature stage 2
picked up (RTD 9 St.2 p.up)
RTD-Box AM ON
OFF
**LEDBO
14201 Fail: RTD10 (broken wire/short-
ed) (Fail: RTD10)
RTD-Box AM ON
OFF
**LEDBO
14202 RTD10 Temperature stage 1
picked up (RTD10 St.1 p.up)
RTD-Box AM ON
OFF
**LEDBO
14203 RTD10 Temperature stage 2
picked up (RTD10 St.2 p.up)
RTD-Box AM ON
OFF
**LEDBO
14211 Fail: RTD11 (broken wire/short-
ed) (Fail: RTD11)
RTD-Box AM ON
OFF
**LEDBO
14212 RTD11 Temperature stage 1
picked up (RTD11 St.1 p.up)
RTD-Box AM ON
OFF
**LEDBO
14213 RTD11 Temperature stage 2
picked up (RTD11 St.2 p.up)
RTD-Box AM ON
OFF
**LEDBO
14221 Fail: RTD12 (broken wire/short-
ed) (Fail: RTD12)
RTD-Box AM ON
OFF
**LEDBO
14222 RTD12 Temperature stage 1
picked up (RTD12 St.1 p.up)
RTD-Box AM ON
OFF
**LEDBO
14223 RTD12 Temperature stage 2
picked up (RTD12 St.2 p.up)
RTD-Box AM ON
OFF
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Typ e
Information Number
Data Unit
General Interrogation
