PROFIBUS DP Communication Module
SIRIUS 3RW44 manual
8-14 GWA 4NEB 535 2195-02 DS 06
9. Select your station address from the dropdown list box on the right-hand side of
the window.
10.Select the "Load to Switching Device" icon in the tool bar.
11.Confirm the station address change with "OK".
12.Confirm the activation of the PROFIBUS DP communication module with "OK".
The PROFIBUS DP communication module has been activated.
13.When the "BUS" LED on the communication module blinks red and the
PROFIBUS icon appears on the display, the communication module has
been activated successfully.
Notice
The soft starter only reads the station address automatically and permanently
saves it when the supply voltage of the soft starter is switched on (refer to
Chapter 8.6.5 "Flow Diagram PROFIBUS DP - Starting the Soft Starter" on Page
8-22) or following a "Restart" command.
