8.12.10 Data Set 93 - Writing a Command
Structure of the command data set
Table 8-25: Structure of the command data set
Table 8-26: Data set 93 - writing a command
Byte Meaning Comment
Preamble
0 Coordination Writing 0x20 via channel C1 (PLC)
Writing 0x30 via channel C2 (PC)
Writing 0x40 via device interface (PC)
1 - 3 Reserved
Command
4 Number of commands Value range 1 ... 5
Number of subsequent valid commands
5 Command 1 For the consecutive number, refer to the table below
6 Command 2 Optional (for coding, refer to the table below)
7 Command 3 Optional (for coding, refer to the table below)
8 Command 4 Optional (for coding, refer to the table below)
9 Command 5 Optional (for coding, refer to the table below)
ID No. Coding Command Meaning
1-byte commands
0 0 Reserved No function
703 1 Trip reset Reset and acknowledgement of error messages
713 2 Emergency start ON Switch on emergency start
714 3 Emergency start OFF Switch off emergency start
709 4 Automatic operating mode Transition to automatic operating mode (DP master-controlled)
710
711
712
5 Operating mode manual
- bus
- operation local
Transition to manual operating mode. The soft starter switches to
manual
bus or manual operation local operating mode, depending on
the interface via which the command is received.
701 6 Restore basic factory
settings
Restore basic factory settings of the parameters.
704 7 Delete maximum pointer The measured values for the preventive diagnosis are deleted (=0).
705 13 Log list -
delete trippings
Delete log list with recorded causes of errors.
706 14 Log list -
delete events
Delete log list with recorded warning messages and certain actions.
702 9 Restart Trigger restarting (same as after line ON), e.g. after reassigning the
station address.
707 10 Parameterization disable
CPU/master ON
No parameterization possible via the parameterizing master, or this
master's parameters are ignored.
708 11 Parameterization disable
CPU/master OFF
Parameterization possible via the parameterizing master.
