Remedy: Match the configuration
data to the
structure or vice versa
Switch on the supply voltage
for the soft starter
The soft starter sets the outputs to "0"
and accepts the set station
address
The soft starter receives
the configuration data from the DP
master
The "BUS" LED lights up green;
Inputs and outputs are enabled; data
exchange is possible
The "BUS" LED is red
No
Yes
Ready for operation
Do the configuration
data match the actual structure?
