8.12.12 Data Set 95 - Reading the Statistics Data
Table 8-28: Data set 95 - reading the statistics data
ID
No.
Byte
Bit
Meaning Value range / [coding] Increment Comment
Statistics
609 0 Motor current I
max
0 ... 797 % / [0 ... 255] 3.125 % 8-bit current
format
1 Reserved = 0
608 2 Last trigger current IA (%) 0 ... 1,000 % / [0 ... 320] 3.125 %
4 Operating hours - device 0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
603 8 - 11 Number of starts motor right 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
604 12 - 15 Number of starts motor left 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
605 16 - 17 Number of overload trips 0 ... 65,535 / [0 ... 65,535] 1
18 Reserved = 0
19 Reserved = 0
607 20 Motor current I
max (rms)
0 ... 20,000 A / [0 ... 2,000,000] 0.01 A
606 24 Last trigger current IA (rms) 0 ... 20,000 A / [0 ...2,000,000] 0.01 A
602 28 Operating hours - motor 0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
611 32 Operating hours - motor current
18 ... 49.9 % x I
e(max)
0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
612 36 Operating hours - motor current
50 ... 89.9 % x I
e(max)
0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
613 40 Operating hours - motor current
90 ... 119.9 % x I
e(max)
0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
614 44 Operating hours - motor current
120 ... 1,000 % x I
e(max)
0 ... 2
32
-1 s / [0 ... 2
32
-1] 1 s
615 48 Reserved = 0
616 50 Number of contact block
overload trips
0 ... 2
32
-1 / [0 ... 2
32
-1] 1
617 52 Reserved = 0
618 54 Reserved = 0
619 56 Reserved = 0
620 60 Number of braking stops 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
621 64 Number of starts - output 1 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
622 68 Number of starts - output 2 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
623 72 Number of starts - output 3 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
624 76 Number of starts - output 4 0 ... 2
32
-1 / [0 ... 2
32
-1] 1
80 Reserved = 0
84 Reserved = 0
88 Reserved = 0
89 Reserved = 0
