9.1.2 3RW44 in a Standard Circuit with Line Contactor and Control via PLC
1) For permissible main and control voltage values, refer to Technical Data, pages 10-12 to 10-16.
2) Caution: risk of restart!
The start command (e.g. via PLC) must be reset when a group fault occurs, since an automatic restart is
executed when a start command is pending after the reset command is issued. This particularly applies to
motor protection tripping.
For safety reasons, we recommend integrating the group error output (terminals 95 and 96) into the control.
Main circuit Control circuit
Standard circuit with optional main contactor Activation of an optional main contactor and activation via PLC
