PROFIBUS DP Communication Module
SIRIUS 3RW44 manual
8-60 GWA 4NEB 535 2195-02 DS 06
8.12.14 Data Set 100 - Reading the Device Identification
Table 8-30: Data set 100 - reading the device identification
*) Time stamp: Time of the initialization with the factory settings in the factory
ID No. Byte
Bit
Value Comment
Preamble
0 Coordination Writing 0x20 via channel C1 (PLC)
Writing 0x30 via channel C2 (PC)
Writing 0x40 via device interface (PC)
1 - 3 Reserved = 0
Device identification (TF)
901 4 - 11 ... Time stamp
*)
902 12 - 31 SIEMENS AG Manufacturer
903 32 - 55 Order number
904 56 0x01 Device family: load feeder
905 57 0x01 Device sub-family: Soft starters
906 58 0x01 Device class: e.g. direct on line starter
907 59 0x03 System: SIRIUS 3RW44
908 60 0x46 Function group
909 61 0x00 Reserved = 0
910 62 - 77 Short product description
911 78 - 81 e.g. E001 HW version (byte 0 to byte 3)
912
82 0x00 ID number (byte 0) (3RW44)
83 0x00 ID number (byte 1) (3RW44)
84 0x80 ID number (byte 2) (3RW44)
85 0xDE ID number (byte 3) (3RW44)
86 - 87 0x00 Reserved = 0
915 88 - 95 ... Service number
96 0x00 Reserved = 0
97 0x00 Reserved = 0
98 0x00 Reserved = 0
99 0x00 Reserved = 0
