PROFIBUS DP Communication Module
SIRIUS 3RW44 manual
GWA 4NEB 535 2195-02 DS 06
8-15
8.5 Soft Starter Configuration
8.5.1 Introduction
This section deals with the configuration and parameterization of soft starters.
• Configuring: Systematic arrangement of the individual soft starters (structure).
• Parameterization: Setting of the parameters using the configuration software.
Further information regarding parameters can be found in Chapter 8.10 "Data
Formats and Data Sets" on Page 8-35.
STEP 7
• The "Diagnose hardware" function is available with STEP 7 V5.1 from
correction version K5.1.2.0 onwards.
• Reloading of the configuration is not supported in STEP 7
(Target system Load to PD).
• It is only possible to read the diagnosis via the CPU 315-2 DP
(using the "Diagnose hardware" function in STEP 7) up to
order number 6ES7315–2AF02.
8.5.2 Configuration with the GSD File
Definition of the GSD
The device master data (GSD) contain DP slave descriptions in a uniform
format. Use of the GSD simplifies the configuration of the DP master and the DP
slave.
Configuration with the GSD File
Soft starters are configured using the GSD file. The soft starter is embedded into
your system as a standard slave via the GSD file.
You can download the GSD file
• from the Internet at
http://support.automation.siemens.com/WW/view/en/113630
The following GSD files are available:
• SIEM80DE.GSG (German)
• SIEM80DE.GSE (English)
• SIEM80DE.GSF (French)
• SIEM80DE.GSI (Italian)
• SIEM80DE.GSS (Spanish)
Notice
Your configuration tool must support GSD files - Rev.3, e.g. STEP 7
V5.1+Service Pack 2 and higher.
