Table 8-32: Data sets 131, 141, 151 - technology parameters 2: reading/writing Set 1, 2, 3
Relations
• Maximum current limit value > minimum current limit value
• DC braking can only be selected when the "DC braking contactor" function is
assigned to an output.
• Max. starting time  starting time
• Limiting torque > start torque
8.12.16 Data Sets 132, 142, 152 - Technology Parameters 3: Reading/Writing Set 1, 2, 3
Table 8-33: Data sets 132, 142, 152 - technology parameters 3: reading/writing Set 1, 2, 3
43 131 Slow speed factor - clockwise rotation 3 ... 21 [3 ... 21] 1
198 132 Slow speed factor - counter-clockwise
rotation
3 ... 21 [3 ... 21] 1
44 133 Slow torque - clockwise rotation 20 ... 100 % [4 ... 20] 5 %
199 134 Slow torque - counter-clockwise rotation 20 ... 100 % [4 ... 20] 5 %
135 -
137
Reserved = 0
ID
No.
Byte
Bit
Meaning
Only for
data set
131
Value range [coding] Factor
Byte
Bit
Value Comment
Preamble
0 Coordination Writing 0x20 via channel C1 (PLC)
Writing 0x30 via channel C2 (PC)
Writing 0x40 via device interface (PC)
1 - 3 Reserved = 0
ID No. Byte
Bit
Meaning Value range [coding] Factor
4 - 9 Reserved = 0
104 10 - 11 Rated operating speed 500 ... 3,600 rpm [500 ... 3,600] 1 rpm
12 - 18 Reserved = 0
113 19 - 20 Rated operating torque 0 ... 65,535 Nm [0 ... 65,535] 1 Nm
21 - 63 Reserved = 0
