Siemens SIRIUS 3RW44 - Page 174

PROFIBUS DP Communication Module
SIRIUS 3RW44 manual
8-50 GWA 4NEB 535 2195-02 DS 06
327 2
3
Thermal motor model overload E4 Overload recognized, the signal bit is updated
continuously.
328 2
4
Overload switch-off E24 The motor is switched off due to a recognized overload.
The signal bit is deleted when the cause for the switch-off
has been remedied and acknowledged via "Trip reset" /
"Autoreset".
329 2
5
Idle time active — The signal bit is updated continuously.
330 2
6
Cool-down time active — The signal bit is updated continuously.
2
7
Reserved = 0 —
3
0-6
Reserved = 0 —
352 3
7
Control input — The device receives control commands via the inputs.
The signal bit is updated continuously.
340 4
0
Asymmetry recognized — There is asymmetry. The signal bit is updated
continuously.
341 4
1
Asymmetry switch-off E24 The motor is switched off due to asymmetry.
The signal bit is deleted when the cause for the switch-
off has been remedied and acknowledged via "Trip
reset".
334 4
2
I
e
limit value exceeded E7 Limit value exceeded.
The signal bit is updated continuously.
335 4
3
I
e
limit value undershot E8 Limit value undershot.
The signal bit is updated continuously.
336 4
4
I
e
limit switch-off E24 The signal bit is deleted when the cause for the switch-
off has been remedied and acknowledged via "Trip
reset".
4
5
Reserved = 0 —
4
6
Reserved = 0 —
339 4
7
Motor stalled - switched off E24 Switch-off, blocking current detected longer than
permissible blocking time. The signal bit is deleted when
the cause for the switch-off has been remedied and
acknowledged via "Trip reset".
344 5
0
Input 1 —
Input statuses:
"1" = active, HIGH level applied
"0" = inactive, LOW level applied
The signal bit is updated continuously.
345 5
1
Input 2 —
346 5
2
Input 3 —
347 5
3
Input 4 —
5
4-7
Reserved = 0 —
342 6
0
Ground fault — There is a ground fault.
The signal bit is updated continuously.
343 6
1
Ground fault switch-off E24 The motor is switched off due to a ground fault.
The signal bit is deleted when the cause for the switch-
off has been remedied and acknowledged via "Trip
reset".
ID
No.
Byte
Bit
Signal bit
E
No.
*)
Meaning/Acknowledgment
