Commissioning
SIRIUS 3RW44 manual
5-6 GWA 4NEB 535 2195-02 DS 06
5.2.2 Quick Start Menu
Important
After applying the control supply voltage for the first time, you will automatically be in the
quick start menu, which you must go through once to commission the soft starter for the
first time.
In the quick start menu, you need to enter the information needed to preset the
most important parameters of the soft starter for your application. Starting
parameters for typical types of applications are stored in the device parameters.
To achieve an optimum motor start, these parameters may need to be optimized
on the basis of the connected load using the "Settings" menu item, as described
in Chapter 5.4.3 "Specifying the Starting Mode".
If your particular load is not listed, select any load and optimize the defined
parameters, if necessary, using the "Settings" menu item as described in
Chapter 5.4.3 "Specifying the Starting Mode".
The values of the basic factory settings of the parameters, and the predefined
assignment of the control inputs and outputs, are listed in Chapter 10.3
"Technical Data".
Important
If you confirm the last item "Save settings - execute?" by entering "Yes" in the quick start
menu, you can only return to this menu by resetting the device back to its basic factory
settings (refer to "Restoring the factory settings" on Page5-40). This overwrites all
settings made up until that point.
