Motor Modules Booksize
6.5 Motor Modules Liquid Cooled
Booksize Power Units
454 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
above/below
in front of the component
mm
≥ 80
kg 21
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC
Characteristics
Motor Modules Booksize Liquid Cooled
Figure 6-94 Duty cycle with initial load (for servo drives)
Figure 6-95 Duty cycle without initial load (for servo drives)
Figure 6-96 S6 duty cycle with initial load with a duty cycle duration of 600 s (for servo drives)
