Page #528 background image
DC link components
8.5 Capacitor Module
Booksize Power Units
528 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
8.5.6
Technical Specifications
Table 8- 21 Technical data
6SL3100-1CE14-0AA0
DC link voltage
V
DC
510 … 720
Electronics power supply V
DC
24 (20.4 … 28.8)
Capacitance
μF
4000
Current carrying capacity
DC link busbar
24 V busbar
A
A
100
20
Power loss (see power loss tables (Page 756))
W
25
Weight
kg
7.2
