Motor-side power components
10.1 Motor reactors
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
565
Note
Maximum cable length of the connection cables
The connection cables to the Motor Module must be kept as short as possib
le (max. 5 m).
10.1.3
Dimension drawings
Figure 10-1 Dimension drawings of motor reactors
