7.8 Technical data
Booksize Power Units
478 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Motor Modules Booksize Compact
6SL3420–
1TE13-0AA.
1TE15-0AA.
1TE21–0AA.
1TE21–8AA.
Electronics current consumption
at 24 VDC
For internal air cooling
For cold plate cooling
A
DC
A
DC
0.85
0.65
0.85
0.65
0.85
0.65
0.85
0.65
Current carrying capacity
DC-link busbars
Reinforced DC-link busbars
24 VDC busbars
A
DC
A
DC
A
DC
100
150
20
100
150
20
100
150
20
100
150
20
Max. current motor brake
A
2
2
2
2
Unit rating
2)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
1.6
1.4
2.7
2.3
4.8
4.1
9.7
8.2
Total power loss
(including electronics losses, see Power loss
tables (Page 756))
Internal air cooling
Cold plate int./ext.
W
W
68 (8 kHz)
25.6/40
98 (8 kHz)
30.6/65
100.4 (4 kHz)
45.6/50
185.4 (4 kHz)
80.6/100
Max. pulse frequency
without derating
with derating
kHz
kHz
8
16
8
16
4
16
4
16
Output frequency
Hz
0 … 550
Sound pressure level with internal air cooling
dB(A)
< 60
< 60
< 60
< 60
Cooling methods
Internal air cooling
Cold plate cooling
Cooling air requirement
with internal air
cooling
m
3
/h 29.6 29.6 29.6 29.6
Max. permissible heatsink temperature
For internal air cooling
For cold plate cooling
° C
° C
73
71
82
75
85
75
90
77
Ventilation clearances
above/below
mm
≥ 80
Weight
kg
2.7
2.7
2.7
3.4
1)
Default setting for 400 V line supplies, undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized line voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC
7.8.2
Double Motor Modules
Table 7- 10 Technical data Double Motor Modules Booksize Compact (2 x 1.7 A to 2 x 5 A)
Double Motor Modules Booksize Compact
6SL3420-
2TE11-7AA.
2TE13-0AA.
2TE15-0AA.
Output current
Rated current (I
n
)
Base-load current (I
H
)
Intermittent duty current (I
S6
) 40%
Peak current (I
max
)
A
AC
A
A
AC
A
AC
2 x 1.7
2 x 1.5
2 x 2
2 x 5.1
2 x 3
2 x 2.6
2 x 3.5
2 x 9
2 x 5
2 x 4.3
2 x 6
2 x 15
Output voltage
V
AC
0 … 0.717 x DC-link voltage
